C# TCP/IP Image transfer - 이미지(파일) 전송 2

C# 2021. 12. 24. 15:19 |
반응형

2021.12.23 - [C#] - C# TCP/IP Image transfer - 이미지(파일) 전송 1 에서 만든 프로그램을 개선해 보자.

네트워크 접속 지연으로 발생할 수 있는 에러를 처리하고 스레드를 사용해 네트워크 접속 대기 시 freeze되는 부분을 개선했다.



폼 디자인은 2021.12.23 - [C#] - C# TCP/IP Image transfer - 이미지(파일) 전송 1 과 동일하다.



1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows.Forms;

using System.Threading;
using System.Net;
using System.Net.Sockets;
using System.IO;

namespace Server
{
    public partial class Form1 : Form
    {
        TcpListener listener;
        TcpClient client;
        NetworkStream networkStream;
        MemoryStream memoryStream;
        Bitmap bitmap;
        IPHostEntry ipHostEntry;
        Thread thread;

        string serverIP;
        int serverPort;
        byte[] data = new byte[1048576]; // 1MB
        byte[] dataSizeFromClient;
        int receivedDataSize;
        int expectedDataSize;

        public Form1()
        {
            InitializeComponent();

            pictureBox1.SizeMode = PictureBoxSizeMode.StretchImage;

            serverPort = 7000;
            // 호스트 이름으로 검색되는 첫 번째 IP4 주소 확인
            string hostName = Dns.GetHostName();
            ipHostEntry = Dns.GetHostEntry(hostName);
            foreach (IPAddress address in ipHostEntry.AddressList)
            {
                if (address.AddressFamily == AddressFamily.InterNetwork)
                {
                    serverIP = address.ToString();
                    break;
                }
            }
            listBox1.Items.Add("Server IP: " + serverIP);

            listener = new TcpListener(IPAddress.Any, serverPort);
            //listener = new TcpListener(IPAddress.Parse("127.0.0.1"), serverPort);
        }

        private void ThreadProc()
        {
            listener.Start();

            client = listener.AcceptTcpClient();
            listBox1.Items.Add("Client IP: " + client.Client.RemoteEndPoint.ToString().Split(':')[0]);

            networkStream = client.GetStream();

            receivedDataSize = 0;
            dataSizeFromClient = new byte[sizeof(int)];

            if (networkStream.CanRead)
            {
                // 클라이언트로 부터 받아야 할 데이터 사이즈 정보 확인.
                networkStream.Read(dataSizeFromClient, 0, dataSizeFromClient.Length);
                expectedDataSize = BitConverter.ToInt32(dataSizeFromClient, 0);
                listBox1.Items.Add("Expected data size: " + (expectedDataSize / 1024).ToString() + "KB");

                // 데이터 송신
                do
                {
                    receivedDataSize += networkStream.Read(data, receivedDataSize, data.Length - receivedDataSize);
                    // Reads data from the NetworkStream and stores it to a byte array.
                } while (networkStream.DataAvailable);
                // while (expectedDataSize > receivedDataSize);
            }

            listBox1.Items.Add("Data received: " + (receivedDataSize / 1024).ToString() + "KB");
            memoryStream = new MemoryStream(data, 0, receivedDataSize);
            // Initializes a new non-resizable instance of the MemoryStream class
            // based on the specified region (index) of a byte array.
            bitmap = new Bitmap(memoryStream);
            pictureBox1.Image = bitmap;

            listener.Stop();
            client.Close();
            networkStream.Close();
            memoryStream.Close();
        }


        private void button1_Click(object sender, EventArgs e)
        {
            // 클라이언트 접속 대기를 위한 스레드 생성(스레드는 1개만 생성한다)
            if (thread == null || !thread.IsAlive)
            {
                thread = new Thread(new ThreadStart(ThreadProc));
                thread.Start();
                listBox1.Items.Add("Waiting for a client...");
            }
        }

        private void Form1_FormClosing(object sender, FormClosingEventArgs e)
        {
            if (thread != null && thread.IsAlive)
            {
                // 클라이언트 접속 대기 종료
                listener.Stop();
                //thread.Abort();
            }
        }
    }
}




서버 코드를 작성하고 빌드한다.



1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows.Forms;

using System.Threading;
using System.Net;
using System.Net.Sockets;
using System.IO;

namespace Client
{
    public partial class Form1 : Form
    {
        TcpClient client;
        NetworkStream networkStream;
        MemoryStream memoryStream;
        Bitmap screen;
        Thread thread;

        string serverIP;
        int serverPort;
        byte[] data;
        byte[] dataSizeForServer;

        public Form1()
        {
            InitializeComponent();

            pictureBox1.SizeMode = PictureBoxSizeMode.StretchImage;
            textBox1.Text = "192.168.0.100";
        }

        private void ThreadProc()
        {
            screen = GetScreen();
            // pictureBox1.Image = screen;
            // 위 명령을 여기서 실행하면 아래와 같은 에러가 발생한다. (이해할 수 없다.)
            // System.InvalidOperationException: 개체를 다른 곳에서 사용하고 있습니다.
            // 서버 접속(아래 try-catch) 이후 실행하면 된다.

            memoryStream = new MemoryStream();

            screen.Save(memoryStream, System.Drawing.Imaging.ImageFormat.Png);
            data = memoryStream.ToArray();

            serverIP = textBox1.Text;
            serverPort = 7000;
            try
            {
                client = new TcpClient(serverIP, serverPort);
            }
            catch (Exception e)
            {
                listBox1.Items.Add(e.Message);
                memoryStream.Close();

                return;
            }

            listBox1.Items.Add("Connected to: " + client.Client.RemoteEndPoint.ToString().Split(':')[0]);
            pictureBox1.Image = screen;

            networkStream = client.GetStream();

            if (networkStream.CanWrite)
            {
                // 보낼 데이터 사이즈를 서버에 미리 공유
                dataSizeForServer = BitConverter.GetBytes(data.Length);
                networkStream.Write(dataSizeForServer, 0, dataSizeForServer.Length);

                // 데이터 전송
                networkStream.Write(data, 0, data.Length);
                listBox1.Items.Add("Data sent: " + (data.Length / 1024).ToString() + "KB");
            }

            client.Close();
            networkStream.Close();
            memoryStream.Close();
        }

        private void button1_Click(object sender, EventArgs e)
        {
            // 클라이언트 접속 대기를 위한 스레드 생성(스레드는 1개만 생성한다)
            if (thread == null || !thread.IsAlive)
            {
                thread = new Thread(new ThreadStart(ThreadProc));
                thread.Start();
                listBox1.Items.Add("Connecting to the server...");
            }
        }

        private Bitmap GetScreen()
        {
            Bitmap bitmap = new Bitmap(Screen.PrimaryScreen.Bounds.Width, Screen.PrimaryScreen.Bounds.Height);
            Graphics g = Graphics.FromImage(bitmap);
            g.CopyFromScreen(0, 0, 0, 0, bitmap.Size);
            g.Dispose();

            return bitmap;
        }
    }
}




클라이언트 코드를 작성하고 빌드한다.



서버 실행 후 클라이언트 접속 대기 상태에서도 freeze 되지 않는다.



클라이언트 실행 후 서버 접속 시도 중인 상태에서도 freeze 되지 않는다. (서버를 실행하지 않고 테스트)





서버 접속에 실패하더라도 클라이언트는 종료되지 않고 에러 메세지만 보낸다.



서버, 클라이언트가 문제 없이 연결되면 정상 작동한다.



※ 참고

2021.12.25 - [C#] - C# TCP/IP Image transfer - 이미지(파일) 전송 3



반응형
